Top/Side Hung Windows

Alu-Clad Top/Side Hung Windows
Specification

Alu-Clad Top/Side Hung Windows

Our Alu-Clad Top/Side Hung Window range is an innovative new window system manufactured from a modern Alu-Clad material.

Reveal Doors and Windows Alu-Clad Top/Side Hung Windows are an ideal choice if you live in a traditional property, or in a conservation area, where the same style has to be retained for planning regulations. They are beautifully built and hand-finished by our expert craftsman to maintain a totally original look.

While you admire the aesthetics on the outside, you can enjoy thermal and acoustic brilliance and the very latest security innovations inside too. Maintenance is also kept to a minimum, with an easy clean material and design that avoids sharp corners.

Specification

Our Alu-Clad Top/Side Hung Windows are ideally suited to residential or commercial use with the following specification, creating endless configurations to meet most needs: –

Opening out, top or side hung
Attractive offering typical sightlines of only 103mm
Frame width of 100mm
Contemporary chamfered sash
Stylish ironmongery with secure multipoint locking
Marine Grade Quality Polyester powder organic coated aluminium to 60 microns to BS 6496
High-quality PEFC sourced European timber
Glazing from 24mm for double or up to 49mm for triple glazed units
Exceeds Building Regulations Document L 2010
Overall Thermal Performance of typically 1.2 W/m²K
Typically window energy “A” rating
Air Permeability to EN 12207: 2000:- Class 4 600Pa
Water tightness to EN 12208: 2000:- Class 9A 600Pa
Resistance to Wind Load to EN 12211: 2000: – Class C3 1200Pa
