Composite Timber Two Pane Sliding Doors

Attractive and modern, Composite Timber Two Pane Sliding Doors make an eye catching and bold statement for any home.

Focusing on stunning glass areas which are highlighted by bold composite timber sections create a streamline and clean aesthetic look.

Our Composite Timber Two Pane Sliding Doors deliver excellent thermal efficiency, which are tested to the highest standards to guarantee reliability.

Composite Timber Two Pane Sliding Doors have enabled the creation of large sliding sashes and glazed areas which flood any space with natural light.


Our Composite Timber Two Pane Sliding Doors are ideally suited to residential or commercial use with the following specification: –

  • Sliding left or right
  • Single sliding door over fixed light
  • Attractive offering typical sightlines of only 123mm
  • Frame width of 172mm
  • Contemporary chamfered sash
  • Stylish ironmongery with secure multipoint locking
  • Marine Grade Quality Organic Polyester powder coated aluminium to 60 microns
  • High-quality PEFC sourced European timber
  • Glazing from 24mm for double or up to 49mm for triple glazed units
  • Exceeds Building Regulations Document L 2010
  • Overall Thermal Performance of typically 1.2 W/m2K
  • Air Permeability to EN 12207: 2000:- Class 4 600Pa
  • Water tightness to EN 12208: 2000:- Class 9A 600Pa
  • Resistance to Wind Load to EN 12211: 2000: – Class C3 1200Pa

Minimum/maximum dimensions

  • Maximum Height 2388mm
  • Minimum Height 1650mm
  • Maximum Width 3988mm
  • Minimum Width 1388mm

Maximum weight

  • Maximum Pane Weight 135Kg

For larger widths or heights, a sidelight and fanlight is available specifically designed to match the Composite Sliding Door outer frame.

Stylish Handles

Composite Timber Sliding Door Handles

Scandinavian Pine

Composite Timber Sliding Door Pine

Great Views

Composite Timber Sliding Door Great Views

Easy Glide

Composite Timber Two Pane Sliding Patio Doors
